Precision Gauge Zinc-Iron Alloy Coated Gi Coil 0.12-4.0mm

Brand Name:	YINGHANG
Model Number:	0.4mm-4mm
MOQ:	25tons
Price:	Price Negotiation
Packaging Details:	According To Customers' Requirement
Payment Terms:	T/T, L/C

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

Coil Od:

Max 1500mm

Zinc:

20gsm-275gsm

Technique:

Cold Rolled,Hot Rolled

Zinc Coating:

40-275g/m2

Length:

1000-12000mm

Business Type:

Manufacturer

Skin Pass:

Price Term:

CIF CFR FOB EX-WORK

Spangle Type:

Regular Spangle

Zinc Layer:

40g-275g

Delivery:

7-10 Days

Id Of Coil:

508/610MM

Standard:

ASTM, JIS, EN, GB

Coating:

30-275g/m2

Port:

Tianjin/Qingdao

Supply Ability:

1000000 tons per year

Highlight:

gi coil precision gauge

0.12-4.0mm Gi coil

4.0mm galvanized coil

Product Description

Galvanized Steel Coil: Superior Corrosion Protection for Demanding Applications

Galvanized steel coil represents a fundamental industrial material manufactured by applying a protective zinc coating to premium cold-rolled or hot-rolled steel substrates through advanced galvanizing processes. This treatment forms a dense, adherent zinc layer on the steel surface, providing exceptional resistance to corrosion and significantly extending the service life of the base metal in diverse and challenging environments. Offering outstanding manufacturability (including stamping, bending, welding), excellent surface quality, and a comprehensive range of specifications (thickness: 0.12-4.0 mm, width: 30-1500 mm), galvanized steel coil serves as an indispensable raw material across numerous sectors such as construction, appliance manufacturing, automotive, general machinery, and agricultural equipment. It underpins the reliability and efficiency of modern manufacturing processes.

Core Specifications & Parameters:

Parameter Range / Options Notes

Thickness (mm) 0.12 - 4.0 Covers ultra-thin gauges to heavy plate

Width (mm) 30 - 1500 Accommodates narrow strip to wide sheet

Coating Weight Standard: Z60-Z275 (g/m²) Customizable (e.g., Z100, Z180, Z275)

Surface Finish Regular Spangle, Minimized Spangle, Spangle-Free Aesthetic and functional options

Coating Type Hot-Dip Galvanized (GI) May include Galvannealed (GA) option

Steel Grade Commercial Quality (CQ), Forming (FQ), Structural (SS Grades), High Strength Low Alloy (HSLA) Suits various mechanical property needs

Standards ASTM A653/A653M, JIS G 3302, EN 10346, GB/T 2518 Compliant with major international norms

Distinctive Features & Manufacturing Advantages:

Robust Corrosion Resistance: The zinc coating acts as a highly effective sacrificial barrier, shielding the underlying steel from oxidation, rust, and atmospheric degradation, even in coastal or industrial environments. This extends service life by 5-8 times compared to uncoated steel.

Enhanced Durability & Longevity: The metallurgical bond between zinc and steel ensures coating adhesion during forming, cutting, and service, providing long-term protection against scratches and abrasion.

Superior Formability & Weldability: Designed for seamless integration into manufacturing processes, our coils exhibit excellent ductility for deep drawing, bending, and roll forming, alongside compatibility with common welding techniques (spot, MIG, TIG).

Consistent Surface Quality: Precise process control delivers uniform coating thickness, minimal defects, and aesthetically pleasing finishes (spangled or smooth) suitable for both exposed and painted applications.

Cost-Effectiveness: Offers an optimal balance between initial material cost and lifecycle value due to reduced maintenance, replacement frequency, and downtime associated with corrosion failure.

Environmental Sustainability: Zinc is a naturally occurring, abundant, and recyclable element. Galvanized steel is 100% recyclable without loss of properties, contributing to circular economy principles.

Key Applications & End-Use Sectors:

The versatility and protective qualities of galvanized steel coil make it essential in countless applications:

Construction: Roofing & wall cladding, structural frames, purlins, trusses, gutters, downpipes, ductwork, scaffolding, formwork, light steel framing (LSF).

Automotive: Body panels (underbody components, brackets, reinforcements), chassis parts, fuel tanks, exhaust systems (heat shields), truck trailers, bus frames.

Appliances: Washing machine drums, refrigerator cabinets & liners, oven housings, air conditioner casings, water heater tanks, microwave oven chassis.

Industrial & Agricultural: Storage tanks, silos, grain bins, HVAC equipment, electrical enclosures, switchboards, conveyor systems, guardrails, fencing, farm equipment (hoppers, feeders, trailers).

Consumer Goods: Shelving units, furniture frames, lighting fixtures, filing cabinets, toolboxes, signage, and various metal containers.

Technology & Underlying Principles:

The predominant technology is Continuous Hot-Dip Galvanizing. The process involves:

Cleaning: Steel strip is thoroughly cleaned (alkaline cleaning, acid pickling) to remove oxides, oils, and mill scale, ensuring perfect zinc adhesion.

Annealing (Optional for CQ/FQ): Strip may be annealed in a reducing atmosphere to restore ductility.

Fluxing: The strip passes through a zinc-ammonium chloride flux solution to prevent oxidation before immersion.

Galvanizing: The clean, fluxed strip is immersed in a molten zinc bath (typically ~450°C / 842°F). A metallurgical reaction occurs between the iron in the steel and the molten zinc, forming a series of zinc-iron alloy layers bonded to the steel substrate, topped by a layer of nearly pure zinc.

Wiping & Cooling: As the strip exits the bath, air knives precisely control the thickness of the outer zinc layer. The coil is then cooled, solidifying the coating.

Passivation & Oiling (Optional): Surface treatments like chromate passivation or oiling may be applied for enhanced corrosion resistance during transit/storage or improved paintability.

Galvannealed (GA) Option: If specified, the hot-dip coated strip undergoes an additional heat treatment immediately after galvanizing. This diffusion process converts the entire coating into a zinc-iron alloy layer, resulting in a matte grey finish with superior paint adhesion, weldability, and resistance to powdering during forming.

Our advanced galvanizing lines ensure precise control over coating weight, surface finish, and mechanical properties, delivering coils that meet the most stringent performance requirements for your specific industrial challenges. Precision Gauge Zinc-Iron Alloy Coated Gi Coil 0.12-4.0mm 0
