Galvalume Steel Coils
>
SGH400 Grade Galvalume Coil Stock For Antifinger Sheet Metal

SGH400 Grade Galvalume Coil Stock For Antifinger Sheet Metal

Brand Name: YINGHANG
Model Number: 0.13MM-5.0MM
MOQ: 25tons
Price: USD500-800/T
Packaging Details: Standard export package or customized
Payment Terms: L/C, T/T
Detail Information
Place of Origin:
CHINA
Certification:
SGS
Product Name:
SGH400 Grade Galvalume Steel Coils For Antifinger Sheet Metal
Keyword:
Galvalume Steel Coils
Grade:
SGCC/DX51D/SPCC/Q235/SGCH/
Aluminium Content:
55%
Application:
Roofing,Construction,corrugated Plate
Coating Type:
Aluminum-Zinc Alloy
Packing:
Standard Export Packing
Width:
914-1250mm
Length:
Customers' Requirement
Zinc Coating:
Az30-az150
Supply Ability:
1000tons one month
Highlight:

Antifinger SGH400 Grade Galvalume Coil

,

Metal SGH400 Grade Galvalume Coil

,

Sheet galvalume steel coils

Product Description

SGH400 Grade Galvalume Steel Coils for Antifinger Sheet Metal





Aluminized zinc steel sheet is an alloy coated steel sheet with the best combination of aluminum and zinc composition and structure. It has the corrosion resistance of aluminum, heat resistance and the electrochemical properties of zinc, and the surface is uniquely smooth, flat and gorgeous spangles , The base color is silver gray: the coating composition is composed of 55% aluminum, 43.4% zinc and 1.6% silicon in weight ratio.



Galvalume Steel Coils Details:



Technical Standard EN10147, EN10142, DIN 17162, JIS G3302, ASTM A653
Steel Grade Dx51D, Dx52D, Dx53D, DX54D, S220GD, S250GD, S280GD, S350GD, S350GD, S550GD; SGCC, SGHC, SGCH, SGH340, SGH400, SGH440, SGH490,
SGH540, SGCD1, SGCD2, SGCD3, SGC340, SGC340 , SGC490, SGC570; SQ CR22 (230), SQ CR22 (255), SQ CR40 (275), SQ CR50 (340), SQ
CR80(550), CQ, FS, DDS, EDDS, SQ CR33 (230), SQ CR37 (255), SQCR40 (275), SQ CR50 (340),
Thickness 0.12-6.00mm,or customer's requirement
Width 600mm-1500mm, according to customer's requirement
Type of Coating Hot Dipped Galvanized Steel(HDGI)
Zinc Coating 10-275g/m2
Surface Treatment Passivation(C), Oiling(O), Lacquer sealing(L), Phosphating(P), Untreated(U)
Surface Structure Normal spangle coating(NS), minimized spangle coating(MS), spangle-free(FS)
Quality Approved by SGS,ISO
ID 508mm/610mm
Coil Weight 3-20 metric ton per coil
Package Water proof paper is inner packing,galvanized steel or coated steel sheet is outer packing , side guard plate,then wrapped by
seven steel belt.or according to customer's requirement
Export market Europe, Africa, Central Asia, Southeast Asia, Middle East, South America, North America, etc



Galvalume Steel Coils Features:



  • Corrosion resistance:When alu-zinc is abraded, aluminum forms a dense layer of alumina that prevents further corrosion of the corrosive material inside.
  • Heat resistance:Aluminum zinc alloy steel has good heat resistance and can withstand high temperatures of more than 300 degrees Celsius.
  • Thermal reflexes:The heat reflectivity of Al-Zn steel plate is very high, which is two times that of galvanized steel sheet.
  • Economical efficiency: Since the density of 55% AL-Zn is smaller than the density of Zn, the aluminum-zinc-plated steel sheet is more than 3% larger than the area of the plated steel sheet when the weight is the same and the thickness of the gold-plated layer is the same.
  • Easy painted:The galvanized sheet has perfect adhesion to the paint, eliminating the need for pre-treatment and weathering of the paint job.The coating material on the galvanized steel sheet has excellent adhesion and can be directly coated on advertising boards and common boards without pre-treatment such as weathering.

Galvalume Steel Coils Package:



Waterproof paper + polyethylene rush inhibitor, the antirust paper , the ring of defends on inside and outside, steel belt, and the guard plate. We can also pack according to your request details.



Galvalume Steel Coils Appliances:

  1. Building & Construction: Roofing; Terrace;Window Frame;
  2. Door: Rolling-up Door;Shutter;Mobile House;
  3. Interior Decorations:Wall; Door Frame;Steel Structure; Screen; Ceiling;Elevator;Household
  4. Appliances: Fridge;Washing Machine; Microwave Oven; Air-Conditioner; DuplicatingMachine, etc;
  5. Transportation: Auto Panel; Interior
