Double Coated PPGI Steel Coils 0.6mm Dx51d for Construction

Brand Name:	YINGHANG
Model Number:	0.12-3.0MM
MOQ:	25tons
Price:	USD500-800/T
Packaging Details:	Export standard packing or according to customers' requirement.
Payment Terms:	L/C,T/T

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

Product Name:

Double Coated Color PPGI Steel Coils 0.6mm Thick Dx51d For Building Materials

Kayword:

PPGI Steel Coils

Packing:

Export Standard Packing Or According To Customers' Requirement.

Color:

Ral Standaed Color

Application:

Construction, Household Appliances, Transportation, Etc.

Material:

Galvanized Steel

Paint Thickness:

Top: 15-25um, Back: 5-10um

Thickness:

0.12mm-1.2mm

Standard:

ASTM, AISI, GB, JIS, DIN

Zinc Coating:

40g-275g/m2

Grade:

SGCC/SGCH/S350GD/S550GD

Width:

600-1250mm

Supply Ability:

1500000/YEAR

Highlight:

Dx51d ppgi coil sheet

0.6mm Thick ppgi coil sheet

0.6mm Thick prepainted galvanized steel coil

Product Description

Double Coated Color PPGI Steel Coils 0.6mm Thick Dx51d For Building Materials

Product Specifications

Attribute	Value
Product Name	Double Coated Color PPGI Steel Coils 0.6mm Thick Dx51d For Building Materials
Packing	Export standard packing or according to customers' requirement
Color	RAL Standard Color
Application	Construction, household appliances, transportation, etc.
Material	Galvanized Steel
Paint Thickness	Top: 15-25um, Back: 5-10um
Thickness	0.12mm-1.2mm
Standard	ASTM, AISI, GB, JIS, DIN
Zinc Coating	40g-275g/m²
Grade	SGCC/SGCH/S350GD/S550GD
Width	600-1250mm

Product Description

PPGI & PPGL (prepainted galvanized steel & prepainted galvalume steel), also known as pre-coated steel or color coated steel coil, is manufactured from hot-dip galvanized steel sheet, hot-dip galvalume steel sheet, or electro galvanized steel sheet. After surface pretreatment, one or several layers of organic coating are applied and baked for solidification.

These color coated steel coils offer lightweight construction, aesthetic appeal, excellent corrosion resistance, and can be directly processed. Available in standard colors including gray, sea blue, and brick red, they are widely used in advertising, construction, decoration, home appliances, furniture, and transportation industries.

PPGI/PPGL Steel Coil Coating Types

Polyester (PE): Excellent adhesion, vibrant colors, good formability, medium chemical resistance, and cost-effective
Silicon modified polyester (SMP): Superior abrasion and heat resistance with good outdoor durability and chalking resistance
High Durability Polyester (HDP): Exceptional UV resistance and color retention with excellent outdoor performance
Polyvinylidene Fluoride (PVDF): Premium UV resistance, outstanding durability, excellent solvent resistance, but with limited color options

Technical Specifications

Parameter	PPGI	PPGL
Base Material	HDGI	HDGL
Thickness	0.19mm-2.0mm	0.2mm-1.5mm
Width	600mm-1500mm	600mm-1250mm
Zinc Coating	Z50g/m²-Z300g/m²	AZ40g/m²-AZ185g/m²
Grade	JIS G3312-CGCC, CGC340-570, (G550) ASTM A755M CS-B, SS255-SS550	JIS G3312-CGCC, CGLCC340-570, (G550) ASTM A755M CS-B, SS255-SS550

Key Advantages

Superior durability and extended service life compared to standard galvanized steel
Excellent heat resistance with minimal discoloration at high temperatures
High thermal reflectivity properties
Excellent processability and welding performance
Competitive pricing with outstanding performance-to-cost ratio

Production Process
