Galvanized Color Coated Steel Coil For Construction

Brand Name:	YINGHANG
Model Number:	PPGI01
MOQ:	25tons
Price:	Price Negotiation
Packaging Details:	Export standard packing or according to customers' requirement.
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

Surface Treatment:

Coated

Surface Production:

PE,PVDF,SMP,HDP,ETC

Special Use:

High-strength Steel Plate

Product Length:

As Per Customer's Requirement

Surface:

PE,PVDF,HDP,SMP

Application:

Roof, Building Material

Product_Type:

Steel Coils

Paint Materials:

RMP,SMP,HDP,PVDF Paint

Back Paint Thickness:

5-10 Microns

Material:

Galvanzied Steel Coil

Top Paint Thickness:

15-25 Microns

Base Metal:

Galvanized Steel Or Galvalume Steel

Inner Diameter:

508mm Or 610mm

Zince Coating:

40-275g/m²

Tolerance:

Supply Ability:

1500000/YEAR

Highlight:

Construction Galvanized Color Coated Steel Coil

Construction Color Coated Steel Coil

color coated steel coil For Construction

Product Description

Galvanized Color Coated Steel Coil for Construction

Color Coated Gi Sheet Product Description

Prepainted galvanized corrugated sheet is also called profiled board. It us- es colored coated steel plate, galvanized plate and other metal plates to roll and cold bend into various wave pro- filed boards. It is suitable for roof, wall and internal and external wall decoration of industrial and civil buildings, warehouses, special buildings and long-span steel struct- ure houses. It has the characteristics of light weight, high strength, rich color, convenient and fast construction, ea- rthquake resistance, fire prevention, rain proof, long ser- vice life, maintenance free and so on.

Color Coated Gi Sheet Product Parameter

Product Name	PPGI Corrugated Roofing Sheets
Technique	Hot Rolled/Hot Dipped/ Cold Rolled
Thickness	0.12mm-1.2mm
Color Coating	RAL colour
Length	2000mm-6000mm or as your request
Width	665mm-1000mm
Steel Grade	DX51D/DX52D/DX53D/DX54D/S250GD/S550GD/SGCC/SGCH/SGCE/CGCC/G350/G4 50/G550/Q195/Q235/Q345/SGLCC/SGLCH
Paint	Top: 10 to 35 um (5 um +12-20 um) Back: 7 +/-2 um
Yidle Strength	550MPA or as your request
Hardness	Full hard/Soft/As your request
Surface Treatment	PE,PVDF,HDP,SMP
Product Application	1. Fence,greenhouse, door pipe 2.Low pressure liquid,water,gas,oil,line pipe 3.For both indoor and outdoor the building construction
MOQ	25tons

PPGI is pre-painted galvanised steel, also known as pre-coated steel, coil coated steel, color coated steel etc., typically with a hot dip zinc coated steel substrate.

The term is an extension of GI which is a traditional abbreviation for Galvanized steel. Today the term GI typically refers to essentially pure zinc (>99%) continuously hot dip coated steel, as opposed to batch dip processes. PPGI refers to factory pre-painted zinc coated steel, where the steel is painted before forming, as opposed to post painting which occurs after forming.

The hot dip metallic coating process is also used to manufacture steel sheet and coil with coatings of aluminium, or alloy coatings of zinc/aluminium, zinc/iron and zinc/aluminium/magnesium which may also be factory pre-painted. While GI may sometimes be used as a collective term for various hot dip metallic coated steels, it more precisely refers only to zinc coated steel. Similarly, PPGI may sometimes be used as a general term for a range of metallic coated steels that have been pre-painted, but more often refers more precisely to pre-painted zinc coated steel.

Zinc coated steel substrate for PPGI is typically produced on a continuous galvanizing line (CGL). The CGL may include a painting section after the hot dip galvanising section, or more commonly the metallic coated substrate in coil form is processed on a separate continuous paint line (CPL). Metallic coated steel is cleaned, pre-treated, applied with various layers of organic coatings which can be paints, vinyl dispersions, or laminates. The continuous process used to apply these coatings is often referred to as Coil Coating.

The steel thus produced in this process is a prepainted, prefinished and ready for further processing into finished products or components. to use material.

The coil coating process may be used for other substrates such as aluminium, or aluminium, stainless steel or alloy coated steel other than “pure” zinc coated steel. However, only “pure” zinc coated steel is typically referred to as PPGI. For example, PPGL may be used for pre-painted 55%Al/Zn alloy-coated steel (pre-painted GALVALUME steel).

Galvanized Color Coated Steel Coil For Construction 0
