Galvanized Welded Wire Mesh 1.2" to 2" Square Hole 3'x100m for Construction

Brand Name:	YINGHANG
Model Number:	1/2"
MOQ:	100 ROLLS
Price:	USD5-50/Rroll
Packaging Details:	waterproof paper and plastic film
Payment Terms:	L/C,T/T

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

Product Name:

1.2" To 2" Square Hole Galvanized Welded Wire Mesh 3'x100m For Buiding

Keyword:

Welded Wire Mesh

Application:

Construction Wire Mesh,Fence Mesh,bridge

Wire Gauge:

BWG#12--#26

Hole Size:

6.35mm-152.4mm(1/4"- 6" )

Width:

0.5m To 2.2m

Surface Treatment:

Galvanized/pvc Coated

Material:

Galvanized Iron Wire

Length:

30m,50m,10m,5m,25m

Packing:

Waterproof Paper,Pallet

Supply Ability:

10000 rolls per week

Highlight:

Square Hole Welded Wire Mesh

3" Welded Wire Mesh

3" welded mesh panels

Product Description

Square Hole Galvanized Welded Wire Mesh Panels 3"X100m For Building

Product Specifications

Attribute	Value
Product Name	1.2" to 2" Square Hole Galvanized Welded Wire Mesh 3'x100m For Building
Application	Construction Wire Mesh, Fence Mesh, bridge
Wire Gauge	BWG#12--#26
Hole size	6.35mm-152.4mm(1/4"- 6")
Width	0.5m to 2.2m
Surface treatment	galvanized/pvc coated
Material	Galvanized Iron Wire
Length	30m,50m,10m,5m,25m
Packing	Waterproof Paper, Pallet

Product Description

Welded wire mesh is made of high quality low carbon steel wire or stainless steel wire, available in hot dipped galvanized and electro galvanized finishes. The zinc coating is applied after welding using automated equipment, resulting in products with smooth mesh surfaces, uniform meshes, strong welded points, and bright luster.

Key features include:

Material: low carbon steel wire
Standard roll length: 30 m
Roll width: 0.5-1.8 m
Wire gauge: 12 G to 21 G
Aperture: 1/2" - 4"
Available as welded mesh roll or welded mesh panel

Available Styles

Electro or Hot dipped galvanized after/before welding
Stainless steel wire welded wire mesh
PVC coated galvanized welded wire mesh
Black wire/uncoated welded wire mesh

Technical Specifications

Mesh Opening	Wire Thickness	Width
1/4 x 1/4 (6 x 6mm)	BWG 26-21 (0.45-0.80mm)	0.3-1.2m
3/8 x 3/8 (10 x 10mm)	BWG 26-19 (0.45-1.00mm)	0.3-1.2m
1/2 x 1/2 (13 x 13mm)	BWG 25-16 (0.50-1.65mm)	0.3-2.0m
1 x 1 (25 x 25mm)	BWG 22-14 (0.70-2.10mm)	0.3-2.0m
2 x 2 (50 x 50mm)	BWG 18-12 (1.20-2.80mm)	0.3-2.0m
4 x 4 (100 x 100mm)	BWG 16-12 (1.60-2.80mm)	0.3-2.0m
6 x 6 (150 x 150mm)	BWG 16-12 (1.60-2.80mm)	0.3-2.0m

Key Benefits

Excellent anti-corrosion and anti-rust properties
Simple installation process
V-braces for enhanced structural strength
Discreet appearance that blends with surroundings
Cost-effective solution
Durable, long-lasting performance

Packaging Options

Waterproof paper and plastic film with label
Waterproof paper and shrink plastic film with label
Custom packaging available upon request
