products details

Home > Products >

Galvalume Steel Coils

G60 AZ40 Galvalume Steel Coils 29-26 Gauge Hot Rolled

All Category

Steel Piles

Mr. Peter Zhang

peter@hbyinghang.com

+8615833385859

Contact Now

G60 AZ40 Galvalume Steel Coils 29-26 Gauge Hot Rolled

Brand Name:	Yinghang
Model Number:	GalvalumeSteelCoil 03
MOQ:	25 tons per size
Price:	USD500-800/T
Packaging Details:	According To Customers' Requirement
Payment Terms:	L/C,T/T,Western Union,MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

SGS ISO

Product Name:

Aluminum-Zinc Alloy Coated Steel Coil Roll

Az Coating:

20-275g/m2

Packing:

Standard Export Packing Or As Per Customer's Request

Coil Weight:

3-8 Tons

Main Market:

Asia,Africa And South America

Material:

Galvalume Steel

Surface Treatment:

Chromate, Oiled, Anti-finger

25 MT

Pass:

ISO14000

Price Term:

EXW;FOB,CFR,CIF

Surface:

Galvalume Coated

Tensile Strength:

G300-G550

Supply Ability:

1000000 tons per year

Highlight:

AZ40 Galvalume Steel Coils

Hot Rolled Galvalume Steel Coils

Regular Spangle galvalume coil

Product Description

G60 AZ40 Galvalume Steel Coils 29 26 Gauge Hot Rolled Regular Spangle

Product Specifications

Attribute	Value
Product Name	Aluminum-Zinc Alloy Coated Steel Coil Roll
Az Coating	20-275g/m2
Packing	Standard Export Packing or as per customer's request
Coil Weight	3-8 tons
Main Market	Asia, Africa and South America
Material	Galvalume Steel
Surface Treatment	Chromate, Oiled, Anti-finger
Min	25 MT
Pass	ISO14000
Price Term	EXW; FOB, CFR, CIF
Surface	Galvalume Coated
Tensile Strength	G300-G550

Product Description

G60 Galvalume Steel Coil Az150 0.43mm 29 26 Gauge Aluminum-Zinc Alloy Coated Steel Coil Roll

Aluminum-Zinc Alloy Coated Steel Product Introduction

Galvalume steel, also known as Aluminum-Zinc Alloy Coated Steel or Zincalume steel, is composed of 55% aluminium, 43.4% zinc and 1.6% silicon solidified at 600°C. Its structure consists of aluminium-iron-silicon-zinc, forming a compact quaternary crystal alloy. The surface features smooth, flat, and attractive spangles with a silver-white base color. The special coating provides excellent corrosion resistance with a normal service life up to 25 years. It maintains good heat resistance in environments up to 315°C, excellent paint adhesion, and superior processing performance for punching, shearing, and welding applications.

Standard	AISI, ASTM, GB, JIS	Material	SGCC, S350GD+Z, S550GD+Z, DX51D, DX52D, DX53D
Thickness	0.12-2.5mm	Width	600-1250mm
Tolerance	+/-0.02mm	Zinc coating	Z30-150g/m2
Coil ID	508/610MM	Coil Weight	3-8 tons
Technique	Hot rolled, cold rolled	Package	Seaworthy package
Color	Blue, Green, Yellow, Golden	HRB	Soft Hard(<60), Medium Hard(60-85), Full Hard(85-95)
Certification	ISO 9001-2008, SGS, CE, BV	MOQ	25 TONS (in one 20ft FCL)
Delivery	15-20 days	Monthly Output	10000 tons
Surface treatment	Oiled(O), Chromium(C), Phosphating(P)	Spangle	Regular Spangle, Minimal Spangle, Zero Spangle, Big Spangle

Standard Packing

Dustproof kraftsheet
Iron Packing
Angle Protective
Packing Belt

Payment Terms

30% T/T in advance + 70% balanced; L/C at sight

Mechanical Properties

Usage	Grade	Yield strength(MPa)	Tensile strength(MPa)
Punching galvanized steel	DC51D+Z	-	270-500
Punching galvanized steel	DC52D+Z	140-300	270-420
Punching galvanized steel	DC53D+Z	140-260	270-380
Structure galvanized steel	S280GD+Z	≥280	≥360
Structure galvanized steel	S350GD+Z	≥350	≥420
Structure galvanized steel	S550GD+Z	≥550	≥560

Key Characteristics

Machinability: Suitable for rolling, coiling, and similar processing requirements
Thermal resistance: Maintains performance at 315°C, compared to 230°C for standard HDG steel
High reflectivity: Reflects twice as much heat and light as standard zinc-coated steel
Corrosion resistance: 2-6 times longer service life than standard galvanized steel

Applications

Ideal for residential and commercial construction products, roofing, wall panels, cabinets, HVAC equipment, electrical boxes, farm equipment, furnace components, guide rails, and home appliances.
