Galvanized Steel Woven Wire Mesh for Filters and Fencing

Brand Name:	Yinghang
Model Number:	wovenwiremesh1
MOQ:	5 tons per size
Price:	USD5-50/Rroll
Packaging Details:	According To Customers' Requirement
Payment Terms:	L/C,T/T,Western Union,MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

SGS ISO

Product Name:

Woven Wire Mesh

Weave Style:

Plain Weave,Twill Weave

Type:

Weave Wire Mesh

Application:

Woven Wire Mesh,Filters,Screen,Protecting Mesh,Decorative Wire Mesh

Color:

Silver,black

Material:

Galvanized Steel Wire

Wire Diameter:

0.6*1.75mm

Usage:

Chmical Industry,Screening,window Curtain

Hole Shape:

Square Hole

Length:

30m/roll 50m/roll Or As Required

Supply Ability:

1000000 tons per year

Highlight:

ODM Woven Mesh Screen

Woven Mesh Screen Fencing

ODM insect netting for windows

Product Description

ODM Woven Mesh Screen Insect Netting For Windows Filter Systems And Fencing

Product Attributes

Attribute	Value
Product name	woven wire mesh
Weave style	Plain Weave, Twill Weave
Type	Weave Wire Mesh
Application	Woven Wire Mesh, Filters, Screen, Protecting Mesh, Decorative wire mesh
Color	Silver, black
Material	Galvanized Steel Wire
Wire diameter	0.6*1.75mm
Usage	chemical industry, Screening, window curtain
Hole shape	Square Hole
Length	30m/roll 50m/roll or as required

Product Description

Woven wire mesh/square wire mesh is made by weaving wires together using materials including galvanized iron wire, black steel wire, stainless steel wire, and copper-clad steel wire. It features excellent corrosion resistance, long service life, and attractive appearance, making it ideal for filter systems, fencing, decorative applications, and safety guards.

Key Features

Strong structure and stable surface
Excellent impact resistance and wear resistance
Uniform mesh size with flat surface and good appearance
High temperature, acid, alkali, and corrosion resistance
Available in various materials and specifications
Easy to process with wide range of applications

Standard Specifications

Mesh Opening (mm)	Wire Dia (mm)	Mesh/Inch	Wire Dia (mm)
2	0.5-1.6	3	0.8-3.0
2.5	0.6-2.0	4	0.6-2.5
3	0.6-2.5	5	0.6-2.0
4	0.6-3.0	6	0.6-1.8
5	0.6-3.5	7	0.6-1.6
6	0.7-3.0	8	0.6-1.5
7	0.8-3.0	10	0.45-1.2
8	0.8-3.5	12	0.45-1.0
10	0.9-6.0	14	0.45-0.8
12	1.0-6.0	16	0.45-0.7
15	1.2-6.0	20	0.45-0.6
20	1.5-6.0	25	1.8-6.0
30	2.0-6.0	40	2.5-6.0

Applications

Architectural uses: Infill panels, balconies, balustrades, windows, decorative screens, fencing, safety guards
Industrial applications: Machine guards, filter screens, sieving systems, ventilation
Agricultural uses: Animal/garden fencing, insect control, greenhouses, coil cribs
Other uses: Display shelves, baskets, bins, barbecue grills, cabinet facing
